The three most important NFC (Near Field Communication) scenarios for Windows 8 / Windows Phone 8 (WP8) app developers: ...

The three most important NFC (Near Field Communication) scenarios for Windows 8 / Windows Phone 8 (WP8) app developers:

- Discover Your App
- Share to Others
- Seamless Multi-User Games & Collaboration

This presentation describes these three scenarios, and shows you how to implement them in C# from a technical perspective. It contains examples for both Windows 8 and Windows Phone 8 development, based on the new Windows Proximity APIs.

In addition, this presentation contains a quick overview of NFC as a technology, as well as pointers towards tools and documentation, including the open source NDEF library for more powerful and sophisticated NFC tag writing and reading tasks.

Statistiques

Vues

Total des vues
5,600
Vues sur SlideShare
5,501
Vues externes
99

Actions

J'aime
4
Téléchargements
164
Commentaires
0

7 Ajouts 99

http://www.scoop.it 52
http://supriyono-regman02.blogspot.com 18
http://www.redditmedia.com 11
http://daniela-dorscheid.de 6
https://twitter.com 4
http://windows8masrapido.blogspot.com 4
http://windows8masrapido.blogspot.mx 4
Plus...

Accessibilité

Catégories

Détails de l'import

Uploaded via as Adobe PDF

Droits d'utilisation

© Tous droits réservés

Report content

Signalé comme inapproprié Signaler comme inapproprié
Signaler comme inapproprié

Indiquez la raison pour laquelle vous avez signalé cette présentation comme n'étant pas appropriée.

Annuler
  • Full Name Full Name Comment goes here.
    Êtes-vous sûr de vouloir
    Votre message apparaîtra ici
    Processing...
Poster un commentaire
Modifier votre commentaire

Windows (Phone) 8 NFC App Scenarios Presentation Transcript

  • 1. Windows (Phone) 8 NFC App Scenarios Andreas Jakl, Mopius Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl NFC Forum and the NFC Forum logo are trademarks of the Near Field Communication Forum. 1
  • 2. Andreas Jakl Twitter: @mopius Email: andreas.jakl@mopius.com Trainer & app developer – mopius.com – nfcinteractor.com Nokia: Technology Wizard FH Hagenberg, Mobile Computing: Assistant Professor Siemens / BenQ Mobile: Augmented Reality-Apps Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 2
  • 3. Near Field Communication Discover Your App NDEF Library Nfc Interactor Share to Others Seamless MultiUser Games & Collaboration Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 3
  • 4. PROXIMITY & TAPPING Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 4
  • 5. NFC Scenarios Connect Devices Exchange Digital Objects Acquire Content Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 5
  • 6. Tap and Do A gesture that is a natural interaction between people in close proximity used to trigger doing something together between the devices they are holding. System: Near Field Proximity (e.g., NFC) Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl Documentation: bit.ly/ProximitySpec 6
  • 7. Proximity APIs Windows Phone 8 + Windows 8 Documentation Win8: bit.ly/ProximityAPI WP8: bit.ly/ProximityAPIwp8 Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 7
  • 8. APP SCENARIOS Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 8
  • 9. Discover Your App Share to Others Seamless Multi-User Games & Collaboration Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 9
  • 10. General Project Setup 1 Add Proximity Capability 2 Initialize ProximityDevice _device = ProximityDevice.GetDefault(); Connect to HW Detect devices in range Publish & subscribe to messages Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 10
  • 11. How to Launch Apps either or Win8 + WP8 Tag directly contains app name and custom data. No registration necessary. Custom URI scheme launches app. App needs to register. Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 11
  • 12. parameters platform 1 app name 1 platform 2 app name 2 … Encoded into NDEF message* Directly launch App Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl * For your low-level interest: type: Absolute URI, type name format: windows.com/LaunchApp. Contents re-formatted, e.g., with string lengths before each value 12
  • 13. Write LaunchApp Tags 1 Launch parameters, platforms + app IDs // Arguments to pass to app, valid for all platforms var launchArgs = "user=default"; // WP8: app's product id from the app manifest, wrapped in {} var wp8App = "{5e506af4‐4586‐4c90‐bc5f‐428b12cf48bc}";  // Win8: app ID: Package.appxmanifest ‐> source ‐> <Application Id="..."> var win8AppId = "Proximity.App"; var win8App = Windows.ApplicationModel.Package.Current.Id.FamilyName + "!" + win8AppId; // Combine to LaunchApp Message var launchAppMessage = launchArgs +  "tWindowsPhonet" + wp8App + "tWindowst" + win8App; Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 13
  • 14. Write LaunchApp Tags 2 Convert to byte array var dataWriter = new Windows.Storage.Streams.DataWriter {UnicodeEncoding = Windows.Storage.Streams.UnicodeEncoding.Utf16LE};    dataWriter.WriteString(launchAppMessage);  3 Write to tags _device.PublishBinaryMessage("LaunchApp:WriteTag", dataWriter.DetachBuffer()); Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 14
  • 15. nearspeak: Good+morning. Protocol name Custom data Encoded Launch URI Examples* skype:mopius?call spotify:search:17th%20boulevard Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl * Definition & examples: http://en.wikipedia.org/wiki/URI_scheme 15
  • 16. User Experience No app installed 1 app installed 2+ apps installed Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 16
  • 17. WP Protocol Association Note: different in Win8 / WP8 1 Specify protocol name in WMAppManifest.xml ...</Tokens> Protocol <Extensions> name <Protocol Name="nearspeak" NavUriFragment="encodedLaunchUri=%s" TaskID="_default" /> Fixed </Extensions> Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 17
  • 18. WP Protocol Association Note: different in Win8 / WP8 2 Create UriMapper class to parse parameters class NearSpeakUriMapper : UriMapperBase { public override Uri MapUri(Uri uri) { // Example: "Protocol?encodedLaunchUri=nearspeak:Good+morning." var tempUri = HttpUtility.UrlDecode(uri.ToString()); var launchContents = Regex.Match(tempUri, @"nearspeak:(.*)$").Groups[1].Value; if (!String.IsNullOrEmpty(launchContents)) { // Launched from associated "nearspeak:" protocol // Call MainPage.xaml with parameters return new Uri("/MainPage.xaml?ms_nfp_launchargs=" + launchContents, UriKind.Relative); } // Include the original URI with the mapping to the main page return uri; }} Argument already handled in step 9 of LaunchApp tags (MainPage.OnNavigatedTo) Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 18
  • 19. WP Protocol Association 3 Use UriMapper in App.xaml.cs (region: ) private void InitializePhoneApplication() { RootFrame = new PhoneApplicationFrame(); RootFrame.UriMapper = new NearSpeakUriMapper(); } – If needed: launch protocol from app (for app2app comm) await Windows.System.Launcher.LaunchUriAsync( new Uri("nearspeak:Good+morning.")); Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 19
  • 20. Register for URI Schemes Win 8 Specify URI scheme, display name + optional im Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 20
  • 21. Tag Data After Launch Win 8 Activtion arguments in App.xaml.cs protected override async void OnActivated(IActivatedEventArgs args) { if (args.Kind == ActivationKind.Protocol) { ProtocolActivatedEventArgs protocolArgs = args as ProtocolActivatedEventArgs; } } Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 21
  • 22. User Experience Win 8 Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 22
  • 23. Discover Your App Share to Others Seamless Multi-User Games & Collaboration Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 23
  • 24. Publish Messages 1 Start publishing _publishingMessageId = _device.PublishUriMessage( new Uri("nfcinteractor:compose")); Proximity devices only – (doesn’t write tags) Contains scheme, platform & App ID Windows Protocol + URI record – Encapsulated in NDEF Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 24
  • 25. Write Tags 1 Prepare & convert data var dataWriter =  new Windows.Storage.Streams.DataWriter {  UnicodeEncoding = Windows.Storage.Streams. UnicodeEncoding.Utf16LE}; dataWriter.WriteString("nfcinteractor:compose"); var dataBuffer = dataWriter.DetachBuffer(); Mandatory encoding 2 Write tag (no device publication) _device.PublishBinaryMessage("WindowsUri:WriteTag", dataBuffer); bit.ly/PublishTypes Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 25
  • 26. Discover Your App Share to Others Seamless Multi-User Games & Collaboration Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 26
  • 27. Seamless MultiUser Games & Collaboration Tap for Quick Data Exchange Long Term Connection ProximityDevice PeerFinder Exchange Windows / NDEF messages, SNEP protocol Automatically builds Bt / WiFi Direct socket connection Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 27
  • 28. Establishing Trigger Long Term Connection Browse Interact with Tap Start Search NFC Bt, WiFi, etc. Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 28
  • 29. Tap to Trigger App not installed App installed Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 29
  • 30. Connection State Proximity gesture complete Devices can be pulled away Which device initiated tap gesture? → Connecting, other device Listening 1 PeerFound 2 Connecting / Listening Access socket of persistent transport (e.g., TCP/IP, Bt) 3 Completed Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 30
  • 31. Find Peers 1 Start waiting for triggered connections PeerFinder.TriggeredConnectionStateChanged += TriggeredConnectionStateChanged; PeerFinder.Start(); 2 Peer found & connection established? Send message over socket private async void TriggeredConnectionStateChanged(object sender,  TriggeredConnectionStateChangedEventArgs eventArgs) { if (eventArgs.State == TriggeredConnectState.Completed) { // Socket connection established! var dataWriter = new DataWriter(eventArgs.Socket.OutputStream); dataWriter.WriteString("Hello Peer!"); var numBytesWritten = await dataWriter.StoreAsync(); 3 }} Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl * For URI records + simple Smart Poster (w/o title), use the WindowsUri type. 31 Completed
  • 32. TOOLS & RESOURCES Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 32
  • 33. UX Recommendations* User initiated peer search only Ask for consent Show connection state Failed connection? Inform & revert to single-user mode Let user get out of proximity experience Proximity: only if connection details not relevant Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl * bit.ly/ProximityUX 33
  • 34. NFC Tools Proximity Tapper for WP emulator – http://proximitytapper.codeplex.com/ Open NFC Simulator – http://open-nfc.org/wp/editions/android/ NFC plugin for Eclipse: NDEF Editor – https://code.google.com/p/nfc-eclipse-plugin/ Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 34
  • 35. nfcinteractor.com Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 35
  • 36. NFC Resources  NFC News: nfcworld.com  NFC developer comparison (WP, Android, BlackBerry): bit.ly/NfcDevCompare  Specifications: nfc-forum.org Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 36
  • 37. Standardized NFC Tag Contents NDEF HANDLING Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 37
  • 38. NFC Data NDEF Record (e.g., URL) … NDEF Message NDEF = NFC Data Exchange Format Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 38
  • 39. SNEP = Simple NDEF Exchange Protocol NDEF Record (e.g., URL) … NDEF Message Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 39
  • 40. Reading NDEF 1 Subscribe to all NDEF messages _subscribedMessageId = _device.SubscribeForMessage( "NDEF", MessageReceivedHandler); 2 Parse raw byte array in handler  http://www.nfc-forum.org/specs/ Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 40
  • 41. Reading NDEF // Convert the language code to a byte array Simple example: assembling payload of Text record 1 Subscribe to all NDEF messages= Encoding.UTF8; var languageEncoding var encodedLanguage = languageEncoding.GetBytes(languageCode); // Encode and convert the text to a byte array var encoding = (textEncoding == TextEncodingType.Utf8) ? Encoding.UTF8 : Encoding.BigEndianUnicode; var encodedText = encoding.GetBytes(text); // Calculate the length of the payload & create the array var payloadLength = 1 + encodedLanguage.Length + encodedText.Length; Payload = new byte[payloadLength]; _subscribedMessageId = _device.SubscribeForMessage( "NDEF", MessageReceivedHandler); 2 Parse raw byte array in handler  // Assemble the status byte Payload[0] = 0; // Make sure also the RFU bit is set to 0 // Text encoding if (textEncoding == TextEncodingType.Utf8) Payload[0] &= 0x7F; // ~0x80 else Payload[0] |= 0x80; http://www.nfc-forum.org/specs/ // Language code length Payload[0] |= (byte)(0x3f & (byte)encodedLanguage.Length); // Language code Array.Copy(encodedLanguage, 0, Payload, 1, encodedLanguage.Length); // Text Array.Copy(encodedText, 0, Payload, 1 + encodedLanguage.Length, encodedText.Length); Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 41
  • 42. NDEF.codeplex.com Create NDEF messages & records (standard compliant) Reusable NDEF classes Parse information from raw byte arrays Fully documented Open Source LGPL license (based on Qt Mobility) Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 42
  • 43. NDEF Subscriptions 1 Subscribe to all NDEF formatted tags _subscribedMessageId = _device.SubscribeForMessage("NDEF", MessageReceivedHandler); 2 Parse NDEF message private void MessageReceivedHandler(ProximityDevice sender,  ProximityMessage message) { var msgArray = message.Data.ToArray(); NdefMessage ndefMessage = NdefMessage.FromByteArray(msgArray); [...] } Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 43
  • 44. NDEF Subscriptions 3 Analyze all contained NDEF records with specialized classes foreach (NdefRecord record in ndefMessage)  { Debug.WriteLine("Record type: " +  Encoding.UTF8.GetString(record.Type, 0, record.Type.Length)); // Check the type of each record ‐ handling a Smart Poster in this example if (record.CheckSpecializedType(false) == typeof(NdefSpRecord))  { // Convert and extract Smart Poster info var spRecord = new NdefSpRecord(record); Debug.WriteLine("URI: " + spRecord.Uri); Debug.WriteLine("Titles: " + spRecord.TitleCount()); Debug.WriteLine("1. Title: " + spRecord.Titles[0].Text); Debug.WriteLine("Action set: " + spRecord.ActionInUse()); } } Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 44
  • 45. Write NDEF 1 Prepare & convert data // Initialize Smart Poster record with URI, Action + 1 Title var spRecord = new NdefSpRecord { Uri = "http://www.nfcinteractor.com" }; spRecord.AddTitle(new NdefTextRecord { Text = "Nfc Interactor", LanguageCode = "en" }); // Add record to NDEF message var msg = new NdefMessage { spRecord }; 2a Write tag // Publish NDEF message to a tag _device.PublishBinaryMessage("NDEF:WriteTag", msg.ToByteArray().AsBuffer()); 2b Publish to devices // Alternative: send NDEF message to another NFC device _device.PublishBinaryMessage("NDEF", msg.ToByteArray().AsBuffer()); Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 45
  • 46. Supported Record Types Smart Poster URI Text LaunchApp Android Application Record (AAR) Windows Phone Settings Nokia Accessories Record NearSpeak Voice Messages Geo tags Social tags SMS tags Telephone call Mailto tags ndef.mopius.com Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 46
  • 47. Near Field Communication Discover Your App NDEF Library Nfc Interactor Share to Others Seamless MultiUser Games & Collaboration Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 47
  • 48. Thank You. Andreas Jakl @mopius mopius.com nfcinteractor.com Windows (Phone) 8 NFC App Scenarios v3.0.0 © 2014 Andreas Jakl 48
