Spring 3.1 and MVC Testing Support

Spring 3.1 and MVC Testing Support Sam Brannen Swiftmind Rossen Stoyanchev SpringSource, VMwareSpringOne 2GXOctober 28, 2011

Sam BrannenSenior Software Consultant @ SwiftmindJava developer with 13+ years experienceSpring Framework Core DeveloperLead author of Spring in a NutshellPrevious SpringSource dm Server™ developerPresenter on Spring, Java, OSGi, and testing

Rossen StoyanchevStaff Engineer SpringSource, VMwareSpring MVC, Spring Web Flow committerTeach and consult, Spring ProjectsSpring Web course authorNYC area

Goals of the PresentationGain an overview of testing featuresin Spring 3.1Learn about the new Spring MVCTest Support project

AgendaSpring TestContext FrameworkTesting with @Configuration ClassesTesting with Environment ProfilesSpring MVC Test SupportQ&A

Show of Hands...JUnit / TestNGSpring 2.5 / 3.0 / 3.1Integration testing with SpringSpring TestContext FrameworkSpring MVCSpring MVC Test Support

Spring TestContext Framework

Introduced in Spring 2.5

Revised in Spring 3.1

Unit and integration testing

Annotation-driven

Convention over Configuration

JUnit & TestNG

Spring & Unit TestingPOJO-based programming modelProgram to interfacesIoC / Dependency InjectionOut-of-container testabilityTesting mocks/stubs for various APIs: Servlet,Portlet, JNDIGeneral purpose testing utilities ReflectionTestUtils ModelAndViewAssert

Spring & Integration Testing ApplicationContext management & caching Dependency injection of test instances Transactional test management with default rollback semantics SimpleJdbcTestUtils JUnit 3.8 support classes are deprecated as of Spring 3.0/3.1

Spring Test AnnotationsApplication Contexts @ContextConfiguration, @DirtiesContext@TestExecutionListenersDependency Injection @Autowired, @Qualifier, @Inject, …Transactions @Transactional, @TransactionConfiguration, @Rollback, @BeforeTransaction, @AfterTransaction

Spring JUnit Annotations Testing Profiles groups, not bean definition profiles @IfProfileValue, @ProfileValueSourceConfiguration JUnit extensions @Timed, @Repeat

Using the TestContext FrameworkUse the SpringJUnit4ClassRunner forJUnit 4.5+Instrument test class withTestContextManager for TestNGExtend one of the base classes Abstract(Transactional)[JUnit4|TestNG]Spri

Example: @POJO Test Classpublic class OrderServiceTests { @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)public class OrderServiceTests { @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)@ContextConfigurationpublic class OrderServiceTests { @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration // defaults to// OrderServiceTests-context.xml in same packagepublic class OrderServiceTests { @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration // defaults to// OrderServiceTests-context.xml in same packagepublic class OrderServiceTests { @Autowired private OrderService orderService; @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration // defaults to// OrderServiceTests-context.xml in same package@Transactionalpublic class OrderServiceTests { @Autowired private OrderService orderService; @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration // defaults to// OrderServiceTests-context.xml in same package@Transactionalpublic class OrderServiceTests { @Autowired private OrderService orderService; @BeforeTransaction public void verifyInitialDatabaseState() { … } @Test public void testOrderService() { … }}

Example: @POJO Test Class@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration // defaults to// OrderServiceTests-context.xml in same package@Transactionalpublic class OrderServiceTests { @Autowired private OrderService orderService; @BeforeTransaction public void verifyInitialDatabaseState() { … } @Before public void setUpTestDataWithinTransaction() { … } @Test public void testOrderService() { … }}

Core Components

TestContextTracks context for current testDelegates to a ContextLoaderCaches ApplicationContext

TestContextManagerManages the TestContextSignals events to listeners: before: before-class methods after: test instantiation before: before methods after: after methods after: after-class methods

TestExecutionListener SPIReacts to test execution events Receives reference to current TestContextOut of the box: DependencyInjectionTestExecutionListener DirtiesContextTestExecutionListener TransactionalTestExecutionListener

TestExecutionListener

TEL: Prepare Instance

TEL: Befores and Afters

ContextLoader SPIStrategy for loading application contexts from resource locationsOut of the box: GenericXmlContextLoader GenericPropertiesContextLoader

ContextLoader 2.5

Putting it all together

New in Spring 3.1

Support for ...

testing with @Configuration classes

testing with environment profiles

made possible by ...

SmartContextLoader

AnnotationConfigContextLoader

DelegatingSmartContextLoader

updated context cache key generation

SmartContextLoader SPISupersedes ContextLoaderStrategy for loading applicationcontextsFrom @Configuration classes orresource locationsSupports environment profiles

ImplementationsGenericXmlContextLoaderGenericPropertiesContextLoaderAnnotationConfigContextLoaderDelegatingSmartContextLoader

ContextLoader 2.5

ContextLoader 3.1

Testing with@Configuration Classes

@ContextConfiguration accepts a new classes attribute...

@ContextConfiguration( classes={DataAccessConfig.class, ServiceConfig.class})

First, a review with XML config for comparison...

OrderServiceTest-context.xml<?xml version="1.0" encoding="UTF-8"?><beans ...>  <bean id="orderService" class="com.example.OrderServiceImpl">  </bean> </beans>

OrderServiceTest.javapackage com.example;@RunWith(SpringJUnit4ClassRunner.class)@ContextConfigurationpublic class OrderServiceTest { @Autowired private OrderService orderService; @Test public void testOrderService() { // test the orderService }}

Lets rework that example to use a @Configuration class and the new AnnotationConfigContextLoader...

OrderServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)public class OrderServiceTest { @Autowired private OrderService orderService; // @Test methods ...}

OrderServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration( loader=AnnotationConfigContextLoader.class)public class OrderServiceTest { @Autowired private OrderService orderService; // @Test methods ...}

OrderServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfigurationpublic class OrderServiceTest { @Autowired private OrderService orderService; // @Test methods ...}

OrderServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfigurationpublic class OrderServiceTest { @Configuration static class Config { } @Autowired private OrderService orderService; // @Test methods ...}

OrderServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfigurationpublic class OrderServiceTest { @Configuration static class Config { @Bean // will be injected into OrderServiceTest public OrderService orderService() { OrderService orderService = new OrderServiceImpl(); // set properties, etc. return orderService; } } @Autowired private OrderService orderService; // @Test methods ...}

Whats changed?No XMLBean definitions are converted toJava using @Configuration and @BeanOtherwise, the test remainsunchanged

But what if we dont want a static inner @Configuration class?

Just externalize the config...

OrderServiceConfig.java@Configurationpublic class OrderServiceConfig { @Bean // will be injected into OrderServiceTest public OrderService orderService() { OrderService orderService = new OrderServiceImpl(); // set properties, etc. return orderService; }}

And reference the config classes in @ContextConfiguration...

OrderServiceConfig.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration(classes=OrderServiceConfig.class)public class OrderServiceTest { @Autowired private OrderService orderService; @Test public void testOrderService() { // test the orderService }}

@Configuration + XML Q: How can we combine @Configuration classes with XML config? A: Choose one as the entry point. Thats how it works in production anyway

Importing Configuration In XML: include @Configuration classes via component scanning or define them as normal Spring beans In an @Configuration class: use @ImportResource to import XML config files

Testing withEnvironment Profiles

@ActiveProfiles To activate bean definition profiles in tests...Annotate a test class with@ActiveProfilesSupply a list of profiles to beactivated for the testCan be used with @Configurationclasses and XML config

Lets look at an example with XML config...

app-config.xml (1/2)<beans ... > <bean id="transferService" class="com.example.DefaultTransferService"> <constructor-arg ref="accountRepository"/> <constructor-arg ref="feePolicy"/> </bean> <bean id="accountRepository" class="com.example.JdbcAccountRepository"> <constructor-arg ref="dataSource"/> </bean> <bean id="feePolicy" class="com.example.ZeroFeePolicy"/> </beans>

app-config.xml (2/2)<beans ... > </beans>

app-config.xml (2/2)<beans ... >  <beans profile="production"> <jee:jndi-lookup id="dataSource" jndi-name="java:comp/env/jdbc/datasource"/> </beans></beans>

app-config.xml (2/2)<beans ... >  <beans profile="production"> <jee:jndi-lookup id="dataSource" jndi-name="java:comp/env/jdbc/datasource"/> </beans> <beans profile="dev"> <jdbc:embedded-database id="dataSource"> <jdbc:script location="classpath:schema.sql"/> <jdbc:script location="classpath:test-data.sql"/> </jdbc:embedded-database> </beans></beans>

TransferServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)public class TransferServiceTest { @Autowired private TransferService transferService; @Test public void testTransferService() { // test the transferService }}

TransferServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration("/app-config.xml")public class TransferServiceTest { @Autowired private TransferService transferService; @Test public void testTransferService() { // test the transferService }}

TransferServiceTest.java@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration("/app-config.xml")@ActiveProfiles("dev")public class TransferServiceTest { @Autowired private TransferService transferService; @Test public void testTransferService() { // test the transferService }}

And now an example with @Configuration classes

TransferServiceConfig.java@Configurationpublic class TransferServiceConfig { @Autowired DataSource dataSource; @Bean public TransferService transferService() { return new DefaultTransferService(accountRepository(), feePolicy()); } @Bean public AccountRepository accountRepository() { return new JdbcAccountRepository(dataSource); } @Bean public FeePolicy feePolicy() { return new ZeroFeePolicy(); }}

} JndiDataConfig.java@Configuration@Profile("production")public class JndiDataConfig { @Bean public DataSource dataSource() throws Exception { Context ctx = new InitialContext(); return (DataSource) ctx.lookup("java:comp/env/jdbc/datasource"); }}

StandaloneDataConfig.java@Configuration@Profile("dev")public class StandaloneDataConfig { @Bean public DataSource dataSource() { return new EmbeddedDatabaseBuilder() .setType(EmbeddedDatabaseType.HSQL) .addScript("classpath:schema.sql") .addScript("classpath:test-data.sql") .build(); }}

And finally the test class...

TransferServiceTest.javapackage com.bank.service;@RunWith(SpringJUnit4ClassRunner.class)public class TransferServiceTest { @Autowired private TransferService transferService; @Test public void testTransferService() { // test the transferService }}

TransferServiceTest.javapackage com.bank.service;@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration( classes={ TransferServiceConfig.class, StandaloneDataConfig.class, JndiDataConfig.class})public class TransferServiceTest { @Autowired private TransferService transferService; @Test public void testTransferService() { // test the transferService }}

TransferServiceTest.javapackage com.bank.service;@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration( classes={ TransferServiceConfig.class, StandaloneDataConfig.class, JndiDataConfig.class})@ActiveProfiles("dev")public class TransferServiceTest { @Autowired private TransferService transferService; @Test public void testTransferService() { // test the transferService }}

Active Profile Inheritance@ActiveProfiles supports inheritance as wellVia the inheritProfiles attributeSee Javadoc for an example

ApplicationContext Caching

Until Spring 3.1

application contexts were cached

but using only resource locations for the key.

Now there are different requirements...

New Key Generation AlgorithmThe context cache key generation algorithm has been updated to include... locations (from @ContextConfiguration) classes (from @ContextConfiguration) contextLoader (from @ContextConfiguration) activeProfiles (from @ActiveProfiles)

SummaryThe Spring TestContext Framework simplifiesintegration testing of Spring-basedapplicationsSpring 3.1 provides first-class testing supportfor: @Configuration classes Environment profilesSee the Testing with @Configuration Classesand Profiles blog for further insight

Spring MVC Test Support

How Do You Test an @Controller?

@Controller@RequestMapping("/accounts")public class AccountController {// ... @ModelAttribute public Account getAccount(String number) { return this.accountManager.getAccount(number); } @RequestMapping(method = RequestMethod.POST) public String save(@Valid Account account, BindingResult result) { if (result.hasErrors()) { return "accounts/edit"; } this.accountManager.saveOrUpdate(account); return "redirect:accounts"; }}

Unit Test? Create controller instanceMock or stub services & repositories

Example@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account");}

Example@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account"); AccountManager mgr = createMock(AccountManager.class); mgr.saveOrUpdate(account); replay(mgr);}

Example@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account"); AccountManager mgr = createMock(AccountManager.class); mgr.saveOrUpdate(account); replay(mgr); AccountController contrlr = new AccountController(mgr); String view = contrlr.save(account, result);}

Example@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account"); AccountManager mgr = createMock(AccountManager.class); mgr.saveOrUpdate(account); replay(mgr); AccountController contrlr = new AccountController(mgr); String view = contrlr.save(account, result); assertEquals("redirect:accounts", view); verify(mgr);}

Example With Failure@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account"); result.reject("error.code", "default message")}

Example With Failure@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account"); result.reject("error.code", "default message") AccountManager mgr = createMock(AccountManager.class); replay(mgr);}

Example With Failure@Testpublic void testSave() { Account account = new Account(); BindingResult result = new BeanPropertyBindingResult(account, "account"); result.reject("error.code", "default message") AccountManager mgr = createMock(AccountManager.class); replay(mgr); AccountController contrlr = new AccountController(mgr); String view = contrlr.save(account, result); assertEquals("accounts/edit", view); verify(mgr);}

Not Fully Tested Request mappings Binding errors Type conversion Etc.

Integration Test? Selenium JWebUnit etc.

It Requires...A running servlet container More time to execute More effort to maintain Server is a black box

Actually...

its an end-to-end test

the only way to verify... Client-side behaviorInteraction with other server instances Redis, Rabbit, etc.

Wed also like to... Test controllers once! Fully & quickly Execute tests often

In summary...We cant replace the need for end-to- end tests But we can minimize errors Have confidence in @MVC code During end-to-end tests

Spring MVC Test Built on spring-test No Servlet container Drives Spring MVC infrastructureBoth server & client-side test support (i.e. RestTemplate code) Inspired by spring-ws-test

The Approach Re-use controller test fixturesI.e. mocked services & repositoriesInvoke @Controller classes through @MVC infrastructure

ExampleString contextLoc = "classpath:appContext.xml";String warDir = "src/main/webapp";MockMvc mockMvc = xmlConfigSetup(contextLoc) .configureWebAppRootDir(warDir, false) .build();mockMvc.perform(post("/persons")) .andExpect(response().status().isOk()) .andExpect(response().forwardedUrl("/add.jsp")) .andExpect(model().size(1)) .andExpect(model().hasAttributes("person"));

Under the CoversMock request/response from spring-test DispatcherServlet replacement Multiple ways to initialize MVC infrastructure Save results for expectations

Ways To Initialize MVC Infrastructure

From Existing XML Config// XML configMockMvc mockMvc = xmlConfigSetup("classpath:appContext.xml") .activateProfiles(..) .configureWebAppRootDir(warDir, false) .build();

From Existing Java Config// Java configMockMvc mockMvc = annotationConfigSetup(WebConfig.class) .activateProfiles(..) .configureWebAppRootDir(warDir, false) .build();

ManuallyMockMvc mockMvc = standaloneSetup(new PersonController()) .setMessageConverters(..) .setValidator(..) .setConversionService(..) .addInterceptors(..) .setViewResolvers(..) .setLocaleResolver(..) .build();

About Manual SetupMVC components instantiated directly Not looked up in Spring context Focused, readable testsBut must verify MVC config separately

TestContext Framework Example@RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration( locations={"/org/example/servlet-context.xml"})public class TestContextTests { @Autowired private WebApplicationContext wac; @Before public void setup() { MockMvc mockMvc = MockMvcBuilders.webApplicationContextSetup(this.wac) .build(); }}

TestContext Framework Caches loaded Spring configuration Potentially across all tests!

However...WebApplicationContext not supported yet To be supported in Spring 3.2

In the mean time...You can use a custom ContextLoader Example exists in spring-test-mvc

Step 1 Add static imports MockMvcBuilders.*MockMvcRequestBuilders.*MockMvcResultActions.*

Easy to remember... MockMvc*

Also in Eclipse...Add MockMvc* classes in Preferences Java -> Editor -> Favorites Helps content assist

Step 2 Initialize MVC infrastructureString contextLoc = "classpath:appContext.xml";String warDir = "src/main/webapp";MockMvc mockMvc = xmlConfigSetup("classpath:appContext.xml") .configureWebAppRootDir(warDir, false) .build()// ...

Step 3 Build RequestString contextLoc = "classpath:appContext.xml";String warDir = "src/main/webapp";MockMvc mockMvc = xmlConfigSetup("classpath:appContext.xml") .configureWebAppRootDir(warDir, false) .build()mockMvc.perform(get("/").accept(MediaType.APPLICATION_XML))// ...

Step 4 Add ExpectationsString contextLoc = "classpath:appContext.xml";String warDir = "src/main/webapp";MockMvc mockMvc = xmlConfigSetup("classpath:appContext.xml") .configureWebAppRootDir(warDir, false) .build()mockMvc.perform(get("/").accept(MediaType.APPLICATION_XML)) .andExpect(response().status().isOk()) .andExpect(response().contentType(MediaType)) .andExpect(response().content().xpath(String).exists()) .andExpect(response().redirectedUrl(String)) .andExpect(model().hasAttributes(String...));// ...

Step 5 DebugString contextLoc = "classpath:appContext.xml";String warDir = "src/main/webapp";MockMvc mockMvc = xmlConfigSetup("classpath:appContext.xml") .configureWebAppRootDir(warDir, false) .build()mockMvc.perform(get("/").accept(MediaType.APPLICATION_XML)) .andPrint(toConsole());// ...

Demohttps://github.com/SpringSource/spring-test-mvc Sample Tests: org.springframework.test.web.server.samples

Client-Side ExampleRestTemplate restTemplate = ... ;MockRestServiceServer.createServer(restTemplate) .expect(requestTo(String)) .andExpect(method(HttpMethod)) .andExpect(body(String)) .andExpect(headerContains(String, String)) .andRespond(withResponse(String, HttpHeaders));

Project Availabilitygithub.com/SpringSource/spring-test-mvc Request for feedback! Send comments Pull requests

Nightly Snapshot Available<repository> <id>org.springframework.maven.snapshot</id> <name>Spring Maven Snapshot Repository</name> <url>http://maven.springframework.org/snapshot</url> <releases> <enabled>false</enabled> </releases> <snapshots> <enabled>true</enabled> </snapshots></repository>

In Closing ...

This PresentationSource:https://github.com/rstoyanchev/spring-31-and-mvc-testing-supportSlides:http://rstoyanchev.github.com/spring-31-and-mvc-test

Resources for Spring MVC TestProject Home:https://github.com/SpringSource/spring-test-mvcSample Tests:org.springframework.test.web.server.samples

Resources for Core SpringSpring Framework:http://www.springsource.org/spring-coreReference Manual: Spring 3.1 RC1Forums: http://forum.springframework.orgJIRA: https://jira.springsource.orgSpring in a Nutshell … available in 2012

Q&A Sam Brannen Web: Swiftmind.com Twitter: @sam_brannenRossen Stoyanchev Web: SpringSource.com Twitter: @rstoya05
